Configuring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 5-17
ENTERING SYSTEM INFORMATION
This section describes how to enter information about the system. This
information is not required for system operation, but can assist in
maintenance and troubleshooting tasks. Tasks describes in this section are:
• setting the system time and date
• setting a password
• labeling the unit and circuit with unique identifiers
You perform all of these tasks from the System Parameters menu. To access
this menu:
1 From the Main Menu, type then press . The System Settings
Menu displays.
3 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:18:41
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
SYSTEM SETTINGS MENU
1) SYSTEM PARAMETERS
2) HDSL PARAMETERS
(R)eturn
ENTER CHOICE>
