Configuring with an ASCII Terminal
5-16 Campus-REX RS Interface Card User Manual
3 To configure the HDSL ES Alarm Threshold, type then press .
The System Parameters menu shows the new HDSL ES Alarm
Threshold setting. Repeat this step until the desired setting displays.
4 To configure the HDSL Margin Alarm Threshold, type then press
.
5 Type the desired margin threshold value, or to disable, then press
. The System Parameters menu shows the new HDSL Margin
Threshold setting. Repeat this step until the desired setting displays.
6 To enable or disable the AutoSync alarm, type then press . The
System Parameters menu shows the new AutoSync alarm setting. Repeat
this step until the desired setting displays.
7 To enable or disable the local LOS alarm, type then press . The
System Parameters menu shows the new Alarm on Local I/F LOS
setting. Repeat this step until the desired setting displays.
8 To enable or disable the remote LOS alarm, type then press
. The System Parameters menu shows the new Alarm on Remote
I/F LOS setting. Repeat this step until the desired setting displays.
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:18:50
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
SYSTEM PARAMETERS
1) Change System Time
2) Change System Date
3) Change Unit ID
4) Change Circuit ID
5) Change Password
6) HDSL ES Alarm Threshold: Disabled (Disabled, 17, 170)
7) HDSL Margin Alarm Threshold: Disabled
8) Autosync Configuration Alarm: Enabled (Enabled, Disabled)
9) Local Data Port LOS Alarm: Disabled (Disabled, Enabled)
10) Remote Data Port LOS Alarm: Disabled (Disabled, Enabled)
11) RESET TO FACTORY DEFAULT
(R)eturn (M)ain Menu
ENTER CHOICE>
6 ENTER
7
ENTER
D
ENTER
8 ENTER
9 ENTER
1 0
ENTER
