Configuring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 5-15
CONFIGURING ALARMS
You can configure four different alarm options:
• HDSL ES Alarm Threshold determines the number of errored seconds
that must occur to trigger an alarm
• HDSL Margin Alarm Threshold determines the margin, in dB, that
triggers an alarm
• Alarm on Local I/F LOS lets you enable or disable the local Loss of
Signal alarm
• Alarm on Remote I/F LOS lets you enable or disable the remote Loss of
Signal alarm
To configure the alarm options:
1 From the Main Menu, type then press . The System Settings
Menu displays.
2 Type then press . The System Parameters menu displays.
3 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:18:41
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
SYSTEM SETTINGS MENU
1) SYSTEM PARAMETERS
2) HDSL PARAMETERS
(R)eturn
ENTER CHOICE>
1 ENTER
