Configuring with an ASCII Terminal
5-14 Campus-REX RS Interface Card User Manual
3 Type then press . The HDSL Parameters menu displays the
new Transceiver Mode setting. Repeat this step until the desired setting
displays.
Dec 9, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 00:27:03
Local Unit ID: Campus REX Unit #34 Local I/F: REX
Remote Unit ID: Campus REX Unit #12 Remote I/F: REX
Circuit ID:
STANDARD MODE HDSL PARAMETERS
1) HDSL Operating Mode: Standard (Standard, Extended)
2) Transceiver Mode: Auto (Master, Slave, Auto)
3) HDSL Rate: T1 (768, T1, E1)
Changes will not be effective until this menu is exited!
(R)eturn (M)ain Menu
ENTER CHOICE>
2 ENTER
