Configuring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 5-13
To change the Transceiver Mode:
1 From the Main Menu, type then press . The System Settings
Menu displays.
2 Type then press . The Standard Mode HDSL Parameters menu
or Extended Mode HDSL Parameters menu displays. The following
illustration shows the Standard Mode HDSL Parameters menu, but the
instructions are identical if the HDSL Operating Mode is set to Extended
Mode.
3 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:18:41
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
SYSTEM SETTINGS MENU
1) SYSTEM PARAMETERS
2) HDSL PARAMETERS
(R)eturn
ENTER CHOICE>
