CONFIGURING STARTUP PARAMETERS
The Campus-REX can take its startup information from its internal NVRAM
or from a network server. For more information about downloading startup
information from a network, see “Management Protocols” on page 7-11.
Set the Boot Mode option to one of the following:
• Local sets the Campus-REX to receive its protocol and network
configuration from internal memory.
• Network sets the Campus-REX to receive its startup data from a network
server.
1 From the Main Menu, type then press . The Data Port Settings
menu displays.
Set the Boot Mode only when the Campus-REX is set as a
bridge. The Boot Mode setting has no effect when the
Campus-REX is in router mode.
2 ENTER
Dec 9, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:16:44
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
DATA PORT SETTINGS
MAC ADDRESS: 00:20:A7:21:2F:6B
10 BASE-T STATUS: Up
1) BRIDGE/ROUTER CONFIGURATION
2) SNMP CONFIGURATION
3) WRITE NVRAM
4) RESET INTERFACE CARD
WARNING: NVRAM must be written and interface card reset for any
configuration changes to take effect.
(R)eturn
ENTER CHOICE>
