Campus-REX RS Interface Card User Manual

Configuring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 5-9
Enabling Authentication Error Trap Generation
To enable authentication error trap generation:
1 From the SNMP Configuration menu, type then press . The
system enables authentication trap generation.
2 Type then press . The system prompts you to enter the IP
address for the first trap receiver.
3 Type the IP address, in decimal-dotted notation, then press . The
SNMP Configuration menu displays.
4 Type then press . The system prompts you to enter the
character string for the first trap receiver.
5 Type a string of up to 64 characters then press . The SNMP
Configuration menu displays. If you are only using one trap receiver, you
have finished setting up authentication error trap generation. Otherwise,
continue to set up the second trap receiver.
6 Type then press . The system prompts you to enter the IP
address for the second trap receiver.
7 Type the IP address, in decimal-dotted notation, then press . The
SNMP Configuration menu displays.
8 Type then press . The system prompts you to enter the
character string for the second trap receiver.
9 Type a string of up to 64 characters then press . The SNMP
Configuration menu displays.
3 ENTER
4 ENTER
ENTER
5 ENTER
ENTER
6 ENTER
ENTER
7 ENTER
ENTER
