Campus-REX RS Interface Card User Manual

Configuring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 5-7
The following SNMP parameters must be set to manage the Campus-REX
over an SNMP network:
• SNMP Read Only Comm String provides the authentication string used
for SNMP read-only operations
• SNMP Read Write Comm String provides the authentication string used
for SNMP read-write operations
You can also set the Campus-REX to perform authentication error trap
generation. To enable this feature, do the following:
• Set the Authentication Trap Status to Enabled or Disabled.
• Enter the IP Address for the first Trap Receiver.
• Enter a comm string for the first Trap Receiver.
• Enter the IP Address for the second Trap Receiver.
• Enter a comm string for the second Trap Receiver.
To configure the SNMP parameters:
1 From the Main Menu, type then press . The Data Port Settings
menu displays.
2 ENTER
Dec 9, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:16:44
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
DATA PORT SETTINGS
MAC ADDRESS: 00:20:A7:21:2F:6B
10 BASE-T STATUS: Up
1) BRIDGE/ROUTER CONFIGURATION
2) SNMP CONFIGURATION
3) WRITE NVRAM
4) RESET INTERFACE CARD
WARNING: NVRAM must be written and interface card reset for any
configuration changes to take effect.
(R)eturn
ENTER CHOICE>
