Configuring with an ASCII Terminal
5-6 Campus-REX RS Interface Card User Manual
3 Type then press .
The system restores the configuration options to their default values.
CONFIGURING THE CAMPUS-REX FOR SNMP
M
ANAGEMENT
The SNMP protocol provides a way to configure the Campus-REX system
over the network. For more information about SNMP management, see
“SNMP” on page 7-11.
Some options, such as the HDSL Rate must be the same for
both the local and remote unit. Resetting the Campus unit
configuration values on one unit only, may cause the HDSL
link to go down.
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:18:50
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
SYSTEM PARAMETERS
1) Change System Time
2) Change System Date
3) Change Unit ID
4) Change Circuit ID
5) Change Password
6) HDSL ES Alarm Threshold: Disabled (Disabled, 17, 170)
7) HDSL Margin Alarm Threshold: Disabled
8) Autosync Configuration Alarm: Enabled (Enabled, Disabled)
9) Local Data Port LOS Alarm: Disabled (Disabled, Enabled)
10) Remote Data Port LOS Alarm: Disabled (Disabled, Enabled)
11) RESET TO FACTORY DEFAULT
(R)eturn (M)ain Menu
ENTER CHOICE>
