Configuring with an ASCII Terminal
5-2 Campus-REX RS Interface Card User Manual
You can also use the LCD and menu buttons on the front of the Campus-RS
Desktop Unit or on the Campus Management Unit (CMU) on the
Campus-Star chassis. To do this, see “Configuring and Monitoring
Through the LCD” on page 4-1.
SETTING UP AND LOGGING ON TO AN
ASCII T
ERMINAL
See “Set Up an ASCII Terminal” on page 3-2 for complete information on
setting up and logging on to the ASCII terminal Main Menu.
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:14:02
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
MAIN MENU
1) SYSTEM STATUS
2) DATA PORT SETTINGS
3) SYSTEM SETTINGS
4) DIAGNOSTICS
5) REMOTE LOGON
(L)ogout
ENTER CHOICE>
