Configuring and Monitoring through the LCD
4-10 Campus-REX RS Interface Card User Manual
Configuring the Alarm
To enable or disable the remote Loss of Signal alarm:
1 From the CURRENT ALARMS display, press Next three times. RMT I/F
ALARMS displays.
2 Press Enter. The current status of the remote alarm displays.
3 Press Next. LOSS OF SIG ALM displays.
4 Press Enter.
5 Press Next to scroll through the settings for the alarm.
6 Press Enter to select the desired setting. RMT LOSS OF SIG ALM
displays.
CONFIGURING LOOPBACKS
Loopbacks provide a way to test the data communication path between the
Campus unit, the remote unit, and the remote host equipment. The
Campus-REX supports two types of loopbacks:
• Local to Remote loopbacks test the remote data port, the data path inside
the remote Campus unit, the HDSL line, the HDSL transceivers of both
units, and most of the internal data path inside the local unit. This
loopback does not test the local data port drivers and receivers.
• Remote to Remote loopbacks test the remote data port and a small
portion of the remote interface card.
Once a loopback condition has been initiated, it remains in effect until
cleared. You may also set a loopback timeout to clear the loopback
automatically after a set period of time has elapsed.
If both the local and remote units have a Campus-REX
interface card, no loopbacks are supported.
