Configuring and Monitoring through the LCD
Campus-REX RS Interface Card User Manual 4-3
7 Press Enter to select and save the desired option.
8 If desired, press Escape several times to return to the top of the menu
structure (CAMPUS RS I/F: REX).
See “LCD Menu Reference” on page A-3 for an illustration of the
hierarchical structure of the LCD menus.
RESTORING THE SYSTEM TO DEFAULT VALUES
You can restore all of the configuration options to their factory default values.
This is an easy way to remove undesired configurations you may have set and
want to return to their former settings.
To return the system configuration options to their default values:
1 Press Escape until CAMPUS RS I/F: REX displays.
2 Press Enter. S/W REV displays.
3 Press Next six times. Press ENTER to factory reset displays.
4 Press Enter. The system configuration options return to the
default values.
Some options, such as the HDSL Rate must be the same for
both the local and remote unit. Resetting the Campus unit
configuration values on one unit only may cause the HDSL
link to go down.
