Set Up the Campus-REX System
Campus-REX RS Interface Card User Manual 3-31
3 Type then press . The Bridge/Router Configuration menu
displays.
4 Type then press . The Timing Source option changes Internal
to HDSL.
5 Repeat the previous step until the Timing Source option is set to the
desired setting.
1 ENTER
Dec 9, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:17:00
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
BRIDGE/ROUTER CONFIGURATION
MODE SETTING 1) Bridge/Router Mode: Bridge (Bridge, Router)
2) Encapsulation: HDLC (HDLC, PPP)
3) Timing Source: Internal (Internal, HDSL)
4) Spanning Tree: Disabled (Disabled, Enabled)
5) Local IP Address: 0.0.0.0
6) Local Subnet Mask: 255.255.255.0
7) Default Router: 0.0.0.0
8) BOOT Mode: Local (Local, Network)
(R)eturn (M)ain Menu
ENTER CHOICE>
3 ENTER
