Set Up the Campus-REX System
Campus-REX RS Interface Card User Manual 3-21
From an ASCII Terminal
1 If you have not already done so, follow the steps in “Set Up an ASCII
Terminal” on page 3-2 to connect the ASCII terminal and log on to the
Main Menu.
2 From the Main Menu, type then press . The Data Port Settings
menu displays.
3 Type then press . The Bridge/Router Configuration menu
displays.
On the Data Port Settings menu, option 4 to Reset the
Interface Card displays only when you have changed
configuration that requires you to save to NVRAM and then
reset the modem to effect the change.
2 ENTER
Dec 9, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:16:44
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
DATA PORT SETTINGS
MAC ADDRESS: 00:20:A7:21:2F:6B
10 BASE-T STATUS: Up
1) BRIDGE/ROUTER CONFIGURATION
2) SNMP CONFIGURATION
3) WRITE NVRAM
4) RESET INTERFACE CARD
WARNING: NVRAM must be written and interface card reset for any
configuration changes to take effect.
(R)eturn
ENTER CHOICE>
1 ENTER
CAD1069i5.book Page 21 Thursday, May 30, 2002 7:32 AM
