Set Up the Campus-REX System
3-20 Campus-REX RS Interface Card User Manual
From the LCD
The steps in this section use the menu buttons and LCD on the front of the
Desktop Unit or the Campus-Star CMU.
To configure the Bridge options:
1 Press Escape until Campus RS I/F: REX displays.
2 Press Next twice, until DATA PORT CONFIG & STATUS displays,
then press Enter. The LCD displays CONFIGURE REX SETTINGS.
3 Press Enter. The LCD displays REX MODE BRIDGE MODE.
4 Press Next twice. ENCAPSULATION displays.
5 Press Enter. The LCD displays the current Encapsulation setting.
6 Press Next until the desired Encapsulation setting displays, then
press Enter.
7 Press Next. SPANNING TREE displays.
8 Press Enter. The LCD displays the current Spanning Tree setting.
9 Press Next until the desired Spanning Tree setting displays, then
press Enter.
10 Press Next. Press Enter to reset interface displays.
11 Press Enter. The Campus-REX restarts with the changes in effect.
If the Campus-REX has been set as a router, you must use an
ASCII terminal if you want to change it back to a bridge. See
“From an ASCII Terminal” on page 3-21.
