Set Up the Campus-REX System
3-18 Campus-REX RS Interface Card User Manual
5 Type the number for the desired HDSL transmission rate then press
. The terminal returns to the HDSL Parameters menu and displays
the new HDSL Rate.
To continue setting up the system, proceed to the next section.
Dec 9, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:19:32
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
SELECT HDSL HIGH RATE
Current HDSL Rate: 256
Current Loop Mode: 2 Loops
1) N/A 13) 1664 kbps
2) 256 kbps 14) 1792 kbps
3) 384 kbps 15) 1920 kbps
4) 512 kbps 16) 2048 kbps
5) 640 kbps
6) 768 kbps
7) 896 kbps
8) 1024 kbps
9) 1152 kbps
10) 1280 kbps
11) 1408 kbps
12) 1536 kbps
(R)eturn (M)ain Menu
ENTER CHOICE>
ENTER
