Set Up the Campus-REX System
3-16 Campus-REX RS Interface Card User Manual
AutoSync HDSL Mode
This section continues from Step 4 on page 3-12 to set up AutoSync HDSL
mode.
To configure AutoSync Mode, you must:
• Set the Transceiver Mode to Master or Slave.
• If the Transceiver Mode is set to Master, set the HDSL Loop Mode to
1 Loop or 2 Loop, depending on the physical layout of your HDSL
network.
• If the Transceiver Mode is set to Master, set the HDSL Rate to one of the
options determined by the HDSL Loop Mode:
– 1 Loop HDSL Rate settings are between 128 kbps and 1.152 Mbps,
in 64 kbps increments.
– 2 Loop HDSL Rate settings are between 256 kbps and 2.048 Mbps,
in 128 kbps increments.
1 From the Standard Mode HDSL Parameters menu, type then press
until the HDSL Operating Mode options changes to AutoSync
Mode. If the terminal is already set to the AutoSync Mode HDSL
Parameters menu, skip this step.
1
ENTER
Dec 9, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:19:32
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
AUTOSYNC MODE HDSL PARAMETERS
1) HDSL Operating Mode: Autosync (Standard, Extended, Autosync)
2) Transceiver Mode: Slave (Master, Slave)
HDSL Loop Mode:
HDSL Rate:
Note:
Remote Unit must be set as Autosync, Master.
Changes will not be effective until this menu is exited!
(R)eturn (M)ain Menu
ENTER CHOICE>
