Set Up the Campus-REX System
3-14 Campus-REX RS Interface Card User Manual
1 From the HDSL Parameters menu, type then press . The
HDSL Operating Mode options changes from Standard Mode to
Extended Mode.
2 To change the HDSL Loop Mode, type then press . Repeat this
step until the desired HDSL Loop Mode setting displays.
3 Type then press . The Select HDSL Rate menu displays.
1 ENTER
Dec 9, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:19:32
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
EXTENDED MODE HDSL PARAMETERS
1) HDSL OPERATING MODE: Extended (Standard, Extended)
2) TRANSCEIVER MODE: Auto (Master, Slave, Auto)
3) HDSL LOOP MODE: 2 Loops (1 Loop, 2 Loops)
4) HDSL RATE: 256
*Note:
1 Loop = single loop, full duplex
2 Loops = two loops, full duplex
Changes will not be effective until this menu is exited!
(R)eturn (M)ain Menu
ENTER CHOICE>
3 ENTER
4 ENTER
