Campus-REX RS Interface Card User Manual

Set Up the Campus-REX System
Campus-REX RS Interface Card User Manual 3-13
To set a Standard HDSL Mode:
1 If the HDSL Operating Mode is set to Extended Mode, type then press
.
2 From the HDSL Parameters menu, type then press . The
HDSL Rate option changes to the next setting.
3 Repeat the previous step until the HDSL Rate option is set to the desired
setting.
4 Type to exit the menu, then confirm any HDSL changes you have
made.
To continue setting up the system, proceed to “Configure the Campus-REX
as a Bridge or Router” on page 3-19.
Extended HDSL Mode
This section continues from Step 4 on page 3-12 to set an extended HDSL
mode.
To set a Standard Mode HDSL Rate, you choose from the list of predefined
rates. To set an Extended Mode HDSL Rate, you must:
• Set the Extended Mode Loop Configuration to 1 Loop or 2 Loop,
depending on the physical layout of your HDSL network.
• Set the Extended Mode HDSL Rate to one of the options determined by
the Extended Mode Loop Configuration:
– 1 Loop HDSL Rate settings are between 128 kbps and 1.152 Mbps,
in 64 kbps increments.
– 2 Loop HDSL Rate settings are between 256 kbps and 2.304 Mbps,
in 128 kbps increments.
1
ENTER
3 ENTER
R
