Using This Manual
iv Campus-REX RS Interface Card User Manual
USING THIS MANUAL
This manual documents the Campus-REX
®
RS Interface Card (part number
150-1175-51). It includes information on how to:
• install the card in either a Campus-RS
™
Desktop Unit (150-1158-01,
150-1158-02, 150-1158-51, or 150-1158-52) or Campus-Star
®
chassis
(150-1220-01, 150-1220-02, or 150-1220-51)
• configure the Campus-REX to operate as a bridge or a router
• monitor the Campus-REX
• contact ADC for assistance.
DOCUMENT CONVENTIONS
Two types of messages, identified by icons, appear in the text.
This manual uses the following conventions:
• This font indicates text that appears on the LCD or terminal.
• Keycaps, such as , indicate keys that you press on a terminal
keyboard.
• Key names in bold font indicate buttons on the desktop unit or line unit
that you press.
For a list of abbreviations used in this manual, see “Abbreviations” on
page B-1.
Notes contain information about special circumstances.
Cautions indicate the possibility of personal injury or
equipment damage.
