Set Up the Campus-REX System
Campus-REX RS Interface Card User Manual 3-5
3 Configure the ASCII terminal to the following communications settings:
• 9600 baud
• no parity
• 8 data bits
• 1 stop bit
• no hardware flow control
Logging Onto the Terminal
1 Press the on the ASCII terminal keyboard several times until
the baud rate is established and the Login Password screen displays on
the terminal monitor.
SPACEBAR
May 3,1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:12:59
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
LOGIN PASSWORD >
