Campus-REX RS Interface Card User Manual 3-1
3
SET UP THE
CAMPUS-REX SYSTEM
There are four sets of configuration options that must be set correctly for the
Campus-REX to operate. With the default settings, the Campus-REX is set to
operate:
• with the HDSL Operating Mode set to Standard Mode
• with the Standard Mode HDSL Rate set to T1
• as a bridge, with the encapsulation format set to HDLC and Spanning
Tree protocol disabled
• with the Timing Source set to Internal
Depending on the requirements of your network, you may be able to use the
default settings for one or more of these options. If so, you can skip the
relevant section(s).
To Learn How to: See Page:
Set Up an ASCII Terminal 3-2
Set the HDSL Operating Mode 3-7
Configure the Campus-REX as a Bridge or Router 3-19
Set the Timing Source 3-29
