Installing the Campus-REX RS Interface Card
2-2 Campus-REX RS Interface Card User Manual
Installing into a Campus-RS Desktop Unit
This section describes how to install the Campus-REX into a Campus-RS
Desktop Unit.
1 Slide the card into the guide rails in the rear of the Desktop Unit.
2 Gently press the card into place until it is seated firmly in the mating
connector.
3 Use the two screws on the card to secure it into place.
4 To connect the Campus system to an HDSL line, see the Campus-RS
Desktop Unit User Manual.
Turn off the power on the Desktop Unit before you install the
card. Installing the card with the power on may cause damage
to the Desktop Unit, the card, or both.
C
A
M
P
U
S
-
R
S
C
O
N
S
O
L
E
L
IN
E
Guide rail
Campus-REX RS
Interface card
Campus-RS Desktop Unit chassis
120 VAC@60Hz
or 220 VAC@50Hz
.2A Max
CFG
E
T
H
E
R
N
E
T
B
R
I
D
G
E
6
3
1
1
0
B
a
s
e
T
L
I
N
K
