Campus-REX RS Interface Card User Manual
Table Of Contents
- About the Product
- Installing theCampusREXRS InterfaceCard
- Set Up the CampusREXSystem
- Configuring andMonitoring throughthe LCD
- Configuring with an ASCII Terminal
- Setting Up and Logging On to an ASCIITerminal
- Logging Onto a Remote Campus Unit
- Logging Off of a Campus Unit
- Using the Terminal Menus
- Returning Configuration Options to Default Values
- Configuring the CampusREX for SNMP Management
- Configuring Startup Parameters
- Configuring the CampusREX as a Master or Slave Unit
- Configuring Alarms
- Entering System Information
- Configuring Loopbacks
- Updating the CampusREX Firmware
- Monitoring with anASCII Terminal
- Internetworking and Management Overview
- Technical Reference
- Abbreviations
- The Documentation Set
- Contacting ADC
About the Product
1-2 Campus-REX RS Interface Card User Manual
PRODUCT FEATURES
The Campus-REX provides complete main bridging tasks such as dynamic
address learning, forwarding, filtering, and hashing/buffer management.
Other features include:
• embedded Simple Network Management Protocol (SNMP) agent
• IEEE 802.1d transparent MAC level bridging with Spanning Tree
protocol support
• static IP Routing
• BOOTP for configuration of IP parameters
• HDLC (High-level Data Link Control) or PPP (Point-to-Point Protocol)
frame encapsulation options
• 10BASE-T port for connection to an 802.3 LAN
• console port for maintenance and management
COMPATIBILITY WITH EARLIER CAMPUS
P
RODUCTS
When mated with a Campus-RS Desktop Unit or Campus-RS Line Unit, the
Campus-REX RS Interface Card is compatible, over the HDSL link, with
earlier versions of Campus products, such as the Campus-T1, Campus-E1,
and Campus-768, as shown in the following illustration. Campus-RS units are
not currently compatible with Campus-384 products.
Campus-REX RS
Interface card
Campus-REX T1,
Campus-REX E1, or
Campus-REX 768
Campus-RS
Campus-T1, Campus-E1 or
Campus-768
HDSL
