Campus-REX RS Interface Card User Manual
Table Of Contents
- About the Product
- Installing theCampusREXRS InterfaceCard
- Set Up the CampusREXSystem
- Configuring andMonitoring throughthe LCD
- Configuring with an ASCII Terminal
- Setting Up and Logging On to an ASCIITerminal
- Logging Onto a Remote Campus Unit
- Logging Off of a Campus Unit
- Using the Terminal Menus
- Returning Configuration Options to Default Values
- Configuring the CampusREX for SNMP Management
- Configuring Startup Parameters
- Configuring the CampusREX as a Master or Slave Unit
- Configuring Alarms
- Entering System Information
- Configuring Loopbacks
- Updating the CampusREX Firmware
- Monitoring with anASCII Terminal
- Internetworking and Management Overview
- Technical Reference
- Abbreviations
- The Documentation Set
- Contacting ADC
Technical Reference
A-2 Campus-REX RS Interface Card User Manual
ADC reserves the right to change features and specifications without notice.
DEFAULT SETTINGS
The following table lists default settings for Campus-REX RS Interface Card
configuration options:
Environmental
Operating Temperature 0° to 50° C
Relative Humidity 0 to 85%
Electromagnetic Emissions Per FCC Part 15 Class A, CE
Safety Compliance UL, CSA, CE
Parameter Default
Bridge/Router Settings
Bridge/Router Mode Bridge
Encapsulation HDLC
Timing Source Internal
Spanning Tree Disable
Boot Mode Local
HDSL Settings
HDSL Mode Standard
HDSL Rate T1
XCVR Mode Auto
Loopback Timeout 20 Minutes
