Internetworking and Management Overview
7-10 Campus-REX RS Interface Card User Manual
The
Internet
IP: 192.168.13.210
Mask: 255.255.255.0
IP: 172.16.100.2
Mask: 255.255.255.0
IP: 192.168.242.1
Mask: 255.255.255.0
DNS Server IP: 192.168.240.20
Mask: 255.255.255.0
IP: 192.168.240.1
Mask: 255.255.255.0
IP: 192.168.240.10
Mask: 255.255.255.0
IP: 192.168.242.5
Mask: 255.255.255.0
Default Gateway: 192.168.242.1
DNS: 192.168.240.20
IP: 172.16.100.1
Mask: 255.255.255.0
Default Gateway: upstream router address: 192.168.13.209
Destination: 192.168.242.0
Mask: 255.255.255.0
Next Hop 192.168.240.10
Default Gateway: 172.16.100.1
Provider Router
Provider Modem
Subscriber Modem
Provider Server
Subscriber PC
Default Gateway: 192.168.240.1
Mask: 255.255.255.0
Destination: 192.168.242.0
Next Hop 172.16.100.2
