Campus-REX RS Interface Card User Manual
Table Of Contents
- About the Product
- Installing theCampusREXRS InterfaceCard
- Set Up the CampusREXSystem
- Configuring andMonitoring throughthe LCD
- Configuring with an ASCII Terminal
- Setting Up and Logging On to an ASCIITerminal
- Logging Onto a Remote Campus Unit
- Logging Off of a Campus Unit
- Using the Terminal Menus
- Returning Configuration Options to Default Values
- Configuring the CampusREX for SNMP Management
- Configuring Startup Parameters
- Configuring the CampusREX as a Master or Slave Unit
- Configuring Alarms
- Entering System Information
- Configuring Loopbacks
- Updating the CampusREX Firmware
- Monitoring with anASCII Terminal
- Internetworking and Management Overview
- Technical Reference
- Abbreviations
- The Documentation Set
- Contacting ADC
Campus-REX RS Interface Card User Manual 7-1
7
INTERNETWORKING AND
MANAGEMENT OVERVIEW
You can configure the Campus-REX as a bridge to forward Ethernet data
based on MAC addresses, or as a router to route Ethernet data based on IP
addresses. You can also configure parameters for management and
encapsulation protocols.
This chapter provides an overview of internetworking and network
management concepts.
For Information About: See Page:
MAC-Level Bridging and Spanning Tree Protocol 7-2
Static IP Routing 7-4
Management Protocols 7-11
Encapsulation Protocols 7-15
