Monitoring with an ASCII Terminal
6-10 Campus-REX RS Interface Card User Manual
VIEWING PRODUCT INFORMATION
The Product Information screen displays manufacturing information about
the Campus-REX RS Interface Card. This information is important if you
ever need to contact ADC for technical support. To open the Product
Information screen:
1 From the Main Menu, type then press . The System Status
screen displays.
2 Type then press . The Product Information screen displays.
The Product Information screen displays the following information:
• the version number of the Campus-REX software (this also displays in
the heading of all the terminal screens)
• the PROM checksum, a hexidecimal number used to verify unit PROMs
• the hardware version of the Campus-REX RS Interface Card
1 ENTER
5 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version 4.1e 13:15:50
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-V.3 Remote I/F: FRAC V.35
Circuit ID: Network Extension Circuit 5001
PRODUCT INFORMATION
Software Version: 4.1e
PROM Checksum: B24E
Hardware Version: FFD0
Desktop
AC
RTC Not Installed
(R)eturn (M)ain Menu
ENTER CHOICE>
