Monitoring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 6-7
2 Type then press . The Local Alarm History screen displays.
This screen shows alarm history of the local unit. If the HDSL line uses two
loops, the screen includes information for both loops. The screen includes
information on the following alarms:
• Errored seconds (ES)
• Margin
• Loss of Signal (LOS)
To view remote alarm history, type then press .
To update the information, type then press .
To clear the information, type then press .
Alarm history information is lost when power is removed from
the Campus unit.
4 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:15:34
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
LOCAL ALARM HISTORY
Type Current First Last Count
HDSL Link, ACTIVE Dec 09, 1999-04:30:03 Nov 31, 1999-12:21:01 1
ES, HDSL-A OFF 0
ES, HDSL-B OFF 0
Margin, HDSL-A OFF 0
Margin, HDSL-B OFF 0
LOS, Port OFF 0
Last Cleared: None
(S)witch to Remote Alarm History
(U)pdate (C)lear
(R)eturn (M)ain Menu
ENTER CHOICE>
S ENTER
U ENTER
C ENTER
