Monitoring with an ASCII Terminal
6-6 Campus-REX RS Interface Card User Manual
To update information on this screen, type then press .
VIEWING LOCAL ALARM HISTORY
To display alarm history information:
1 From the Main Menu, type then press . The System Status
Menu displays.
Performance history information is lost when power is
removed from the Campus unit.
U ENTER
1 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:14:18
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
SYSTEM STATUS MENU
1) CURRENT SYSTEM STATUS
2) 24 HOUR HDSL PERFORMANCE HISTORY
3) 7 DAY HDSL PERFORMANCE HISTORY
4) LOCAL ALARM HISTORY
5) PRODUCT INFORMATION
(R)eturn
ENTER CHOICE>
