Monitoring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 6-5
To view more history information:
• To view the next page of the report, type then press .
• To view the previous page, type then press .
To update information on this screen, type then press .
Seven-Day Performance History
To display HDSL information for the last seven days:
1 From the Main Menu, type then press . The System Status
Menu displays.
2 Type then press . The 7 Day HDSL Performance History
screen displays.
Performance history information is lost when power is
removed from the Campus unit.
N ENTER
P ENTER
U ENTER
1 ENTER
3 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:15:13
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
7 DAY HDSL PERFORMANCE HISTORY
HDSL-A HDSL-B
LOCAL REMOTE LOCAL REMOTE
ES/UAS ES/UAS ES/UAS ES/UAS
-------- -------- -------- --------
Jan 24 00000/00000 00000/00000 00000/00000 00000/00000
Jan 25 00000/00000 00000/00000 00000/00000 00000/00000
Jan 26 00000/00000 00000/00000 00000/00000 00000/00000
Jan 27 00000/00000 00000/00000 00000/00000 00000/00000
Jan 28 00000/00000 00000/00000 00000/00000 00000/00000
Jan 29 00000/00000 00000/00000 00000/00000 00000/00000
Jan 30 00000/00000 00000/00000 00000/00000 00000/00000
Jan 31* 00000/00000 00000/00000 00000/00000 00000/00000
*Since Midnight
(U)pdate
(R)eturn (M)ain Menu
ENTER CHOICE>
