Monitoring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 6-3
2 Type then press . The Current System Status menu displays.
The Current System Status menu provides the following information:
• Local Alarms indicates the current local alarm status
• Remote Alarms indicates the current remote alarm status
• Loopback indicates the current loopback status
• Margin indicates the minimum (mn), current (cr), and maximum (mx)
HDSL margin value, measured in dB, relative to the signal-to-noise ratio
required for a Bit Error Rate (BER) of 10
-7
• Pulse Attn indicates the decrease in amplitude of the transmitted signal
as measured at the HDSL receiver
• 24 Hour ES indicates the number of errored seconds over the last
24 hours
• 24 Hour UAS indicates the number of unavailable seconds over the last
24 hours
• Last Cleared indicates the date and time when the error counter was last
cleared
1 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:14:35
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
CURRENT SYSTEM STATUS
Local Alarms:
Remote Alarms:
Loopback: None
HDSL-A HDSL-B
LOCAL REMOTE LOCAL REMOTE
-------- -------- -------- --------
mn/cr/mx mn/cr/mx mn/cr/mx mn/cr/mx
Margin (dB): na/na/na na/na/na na/na/na na/na/na
Pulse Attn (dB): 00 00 00 00
24 Hour ES: 00000 00000 00000 00000
24 Hour UAS: 05671 00000 05671 00000
Last Cleared: None
(U)pdate (C)lear
(R)eturn (M)ain Menu
ENTER CHOICE>
