3.1 The Setup Program
The setup program is used to configure system options on ISA and EISA
machines. The system options include such things as diskette and hard disk
options, video subsystem, and system memory. These parameters are
controlled by system BIOS and, hence, need to be modified before the operating
system boots.
To access the setup program:
1. Turn on the server and watch the screen.
The BIOS level appears.
2. When the message
Press <F2> to enter SETUP
appears, press F2.
3. Follow the instructions on the screen to view or change the configuration.
Please see the following sections for detailed instructions on this process.
After completion of these operations:
1. Select Exit menu from the menu bar.
Don′t forget to select Saves changes and exit.
The setup program consists of three panels which are selectable from the menu
bar:
•
Main
•
Advanced
•
Security
3.1.1 Main Menu
Figure 23 shows the main panel of the setup program.
Phoenix BIOS Setup - Copyright 1985-94 Phoenix Technologies Ltd.
Main Advanced Security Exit
System Time : [13:43:04]
System Date : [08/23/1995]
Diskette A: [1.44 MB, 3½†]
Diskette B: [Not Installed]
IDE Device 0 Master (None)
IDE Device 0 Slave (None)
IDE Device 1 Master (None)
IDE Device 1 Slave (None)
Video System: [VGA/SVGA]
Video BIOS Shadow: [Enabled]
System Memory: 640KB
Extended Memory: 15MB
Cache State: [Enabled]
Figure 23. PC Server 320 Setup Program - Main Menu
