2.1.7 IBM PC Server 520 MCA
Table 14. IBM PC Servers 520 MCA Models
System
Model
8641
MZ0
8641
MZV
8641
MZS
8641
MZE
8641
MZL
Processor Pentium 100 Pentium 100 Pentium 100 Pentium 100 Pentium 100
SMP 1-2 P100 1-2 P100 1-2 P100 1-2 P100 1-2 P100
Bus Architecture PCI/MCA PCI/MCA PCI/MCA PCI/MCA PCI/MCA
Disk Controller PCI SCSI-2
F/W
PCI SCSI-2
F/W
PCI SCSI-2
F/W RAID
PCI SCSI-2
F/W RAID
PCI SCSI-2
F/W RAID
Hard File Size None 2.25GB 2 * 2.25GB 4 * 2.25GB 6 * 2.25GB
Std Memory (MB) 32/256 32/256 32/256 32/256 32/256
L2 Cache (KB) 512 512 512 512 512
Graphics SVGA SVGA SVGA SVGA SVGA
62 NetWare Integration Guide
