2.1 IBM PC Server Model Specifications
The following tables show the specifications for each model in the current line.
They are included for a reference of the standard features of each line.
2.1.1 IBM PC Server 300
Table 8. IBM PC Servers 300 Models
System
Model
8640
0N0
8640
ONJ
8640
0P0
8640
0PT
Processor 486DX2/66 486DX2/66 Pentium 60 Pentium 60
Bus Architecture PCI/EISA PCI/EISA PCI/EISA PCI/EISA
Disk Controller PCI IDE
ISA IDE
PCI IDE
ISA IDE
PCI SCSI-2 Fast
ISA IDE
PCI SCSI-2 Fast
ISA IDE
STD Hard File Size None 728MB IDE None 1GB SCSI-2
Memory Std/Max (MB) 8/128 8/128 16/192 16/192
L2 Cache Std/Max (KB) 256/256 256/256 256/512 256/512
Graphics VGA VGA VGA VGA
