Disk
Controller
DATA AAA BBB CCC
DATA MIRROR CCC AAA BBB
DATA DDD EEE FFF
DATA MIRROR FFF DDD EEE
Disk 1 Disk 2 Disk 3
Figure 14. RAID-1 Enhanced, Data Strip Mirroring
Some vendors have also implemented another slight variation of RAID-1 and
refer to it as RAID-10 since it combines features of RAID-1 and RAID-0. Others
refer to this technique as RAID-6, which is the next available RAID level.
As shown in Figure 15, this solution consists of mirroring a striped (RAID-0)
configuration. In this example, a RAID-0 configuration consisting of 2 drives
(drive 1 and 2) is mirrored to drives 3 and 4.
Disk
Controller
AAA BBB AAA BBB
CCC DDD CCC DDD
EEE FFF EEE FFF
GGG HHH GGG HHH
Disk 1 Disk 2 Disk 3 Disk 4
Figure 15. RAID-6,10 - Mirroring of RAID 0 Drives
Performance and capacity are similar to RAID 1. 50% of total disk capacity is
usable. However, this solution always uses an
even
number of disks. RAID-1
enhanced can use an
odd
number of disks. RAID-1 also can be mixed with
others RAID levels.
26 NetWare Integration Guide
