IBM RAID Controller Configuration Ver 2.12
Adapter in Slot 1
Create/Delete Array
Ch1Ch2
1. Help Bay Bay
2. Define hot-spare drive Array Array
3. Delete disk array
4. Create disk array 1 1
5. Define Logical drive
6. Format drive 2 2
7. Exit
3 HSP 3
4 ONL A 4
Array Arrays Log Size RAID Date
ID Size (MB) Drv (MB) Level Created 5 ONL A 5
A 6450 A0 400 RAID-5 08/24/95 6 ONL A 6
7 7
Figure 66. RAID Configuration Program - Size Definition
7. Repeat the procedures for the other logical drives and arrays.
Note
It is not necessary to define multiple logical drive of same RAID level.
You can partition these logical drives the same way you partition a real
disk when you install the operating system.
8. Select Exit to leave this menu.
9. Select Yes to save the changes.
Figure 67 shows an example completed array definition which includes two
logical drives: one 400MB RAID-5 array and one 2925MB RAID-1 array.
IBM RAID Controller Configuration Ver 2.12
Adapter in Slot 1
Ch1Ch2
Bay Bay
Array Array
1 1
2 2
3 HSP 3
4 ONL A 4
Array Arrays Log Size RAID Date
ID Size (MB) Drv (MB) Level Created 5 ONL A 5
A 6450 A0 400 RAID-5 08/24/95 6 ONL A 6
A1 2925 RAID-1 08/24/95
7 7
Figure 67. RAID Configuration Program - Result
Chapter 3. Hardware Configuration 111
