3.5.5 Defining Logical Drives
1. Select Define logical drive from the Create/Delete Array menu. The following
screen appears:
IBM RAID Controller Configuration Ver 2.12
Adapter in Slot 1
Create/Delete Array
Ch1Ch2
1. Help Bay Bay
2. Define hot-spare drive Array Array
3. Delete disk array
4. Create disk array 1 1
5. Define Logical drive
6. Format drive 2 2
7. Exit
3 HSP 3
4 ONL A 4
Array Arrays Log Size RAID Date
ID Size (MB) Drv (MB) Level Created 5 ONL A 5
A 6450 6 ONL A 6
7 7
Figure 63. RAID Configuration Program - Logical Drive Definition
2. Highlight the array to be defined and press Enter.
The define logical drive pop-up window appears.
IBM RAID Controller Configuration Ver 2.12
Adapter in Slot 1
Select Create/Delete Array
RAID Ch 1 Ch 2
Level 1. Help Bay Bay
2. Define hot-spare drive Array Array
1. RAID-5 3. Delete disk array
2. RAID-0 4. Create disk array 1 1
3. RAID-1 5. Define Logical drive
6. Format drive 2 2
7. Exit
3 HSP 3
4 ONL A 4
Array Arrays Log Size RAID Date
ID Size (MB) Drv (MB) Level Created 5 ONL A 5
A 6450 6 ONL A 6
7 7
Figure 64. RAID Configuration Program - Logical Drive Definition - Array Selection
Chapter 3. Hardware Configuration 109
