- ITSO Technical Bulletin Evaluation RED000

IBM RAID Controller Configuration Ver 2.12
Adapter in Slot 1
Create/Delete Array
Ch1Ch2
1. Help Bay Bay
2. Define hot-spare drive Array Array
3. Delete disk array
4. Create disk array 1 1
5. Define Logical drive
6. Format drive 2 2
7. Exit
3 RDY 3
4 RDY 4
5 RDY 5
6 RDY 6
7 7
Figure 60. RAID Configuration Program - Create/Delete Array Menu
1. Select Define hot-spare drive. The cursor becomes active in the Bay/Array
selection list.
2. Use the up and down arrow keys to select the RDY (ready) drive to be used
as a hot-spare and press Enter. The RDY status changes to HSP (hot-spare).
Figure 61 shows an example where a hot-spare disk has been defined.
3. Press Esc to validate.
Notes:
1. The hot-spare drive is not associated with any array. If more than one array
is defined, you need only 1 hot-spare drive for all the arrays.
2. If the disks have different sizes, the hot-spare drive must be the largest.
IBM RAID Controller Configuration Ver 2.12
Adapter in Slot 1
Create/Delete Array
Ch1Ch2
1. Help Bay Bay
2. Define hot-spare drive Array Array
3. Delete disk array
4. Create disk array 1 1
5. Define Logical drive
6. Format drive 2 2
7. Exit
3 HSP 3
4 RDY 4
5 RDY 5
6 RDY 6
7 7
Figure 61. RAID Configuration Program - Hot-Spare Disk Definition
Chapter 3. Hardware Configuration 107
