The common configuration tasks that will be described here are as follows:
1. Verify the configuration
2. Low-level format of the disks
3. Defining a hot-spare drive
4. Creating a disk array
5. Defining logical drives
6. Look at the drives information
7. Backup/restore the configuration
After booting with the RAID Controller program diskette, if more than one RAID
adapter is installed, it will prompt you to select which adapter you want to work
with (see Figure 54). Otherwise, a screen like the one in Figure 55 will appear.
IBM RAID Controller Configuration Ver 2.12
Select Adapter
1. Help
2. RAID Controller in slot 1
3. RAID Controller in slot 2
4. Exit
Figure 54. RAID Configuration Program - Adapter Selection
Use the arrow keys to select the adapter you want to configure and press Enter.
A screen like the one in Figure 55 will appear.
IBM RAID Controller Configuration Ver 2.12
Adapter in Slot 1
Main Menu
1. Help
2. View configuration
3. Create/delete Array
4. Initialize/synchronize array
5. Rebuild device
6. Advanced functions
7. Drive information
8. Exit
Figure 55. RAID Configuration Program - Main Menu
