Main Menu
Select one:
1. Start Operating System
2. Backup/Restore system programs
3. Update system programs
4. Set configuration
5. Set Features
6. Copy an option diskette
7. Test the computer
8. More utilities
Enter F1=Help F3=Exit
Figure 39. System Programs - Main Menu
3.4.2 Starting From the Reference Diskette
To start the system programs from the reference diskette:
1. Turn off the server.
2. Insert the reference diskette into your diskette drive.
3. Turn on the system.
After a few moments, the system programs Main Menu appears. It will look
similar to the one in Figure 39.
To select an option:
1. Use the up arrow key or down arrow key to highlight a choice.
2. Press Enter.
3.4.3 Main Menu Options
The following are the options available on the Main Menu. Included with each
option is a brief description of its purpose.
1. Start operating system
Exits from the system programs and loads the operating system.
2. Backup/restore system program
Makes a backup copy of the system programs from the hard disk to diskette
or restores the system programs from the diskette to hard disk.
3. Update system programs
84 NetWare Integration Guide
