3.3 SCSI Select Utility Program
This utility is used on PCI/EISA models of the IBM PC Server line and allows the
user to:
•
View and modify parameters for the SCSI controller
•
View and modify parameters of SCSI devices
•
Perform low-level formatting of attached SCSI hard disks
To access the SCSI Select Utility Program:
•
Turn on the server and watch the screen
•
When the message Press <Ctrl><A> appears, press Ctrl and A
simultaneously.
A screen like the one in Figure 34 will appear.
Adapter AHA-2940/AHA-2940W SCSISelect(Tm) Utility
Would you like to configure the host adapter, or run the
SCSI disk utilities? Select the option and press <Enter>
Press <F5> to switch between color and monochrome modes
Options
Configure/View Host Adapter Settings
SCSI Disk Utilities
Figure 34. IBM PC Server SCSISelect Utility Program - Main Menu
•
Press Enter to enter the Configure/View Host Adapter. option
A screen like the one in Figure 35 will appear.
Configuration/View Host Adapter Settings
Configuration
SCSI Bus Interface Definitions
Host Adapter SCSI ID ........................ 7
SCSI Parity Checking ........................ Enabled
Host Adapter SCSI Termination ............... Low ON/High OFF
Additional Options
SCSI Device Configuration ................... Press <Enter>
Advanced Configurations Options ............. Press <Enter>
<F6> - Reset to Host Adapter Defaults
Figure 35. IBM PC Server SCSI Select Utility Program - Host Adapter Settings
