Connectors
This section provides a description of the connectors on the SAS HBA.
PCI Express connector — The PCI Express interface has eight PCI Express lanes (in
two connectors) which provide possible host-side maximum transmission and
reception rates of up to 4.0 Gbytes/s.
SAS/SATA connectors — The SAS connectors are SFF-8087 mini-SAS x4 connectors.
PCI Performance
PCI performance features of the SAS HBA include:
■ Provides eight PCI Express PHYs
■ Supports x8, x4, and x1 link widths
■ Supports serial, point-to-point interconnections between devices
■ Supports lane reversal and polarity inversion
■ Supports PCI Express Hot Plug
■ Supports Power Management
■ Supports PCI Power Management 1.2
■ Supports Active State Power Management (ASPM), including the L0, L0s, L1
states, by placing links in a power-saving mode during times of no link activity
■ Contains a replay buffer that preserves a copy of the data for retransmission in
case a CRC error occurs
■ Supports the PCI Express Advanced Error Reporting capabilities
■ Provides quality of service (QOS) link configuration and arbitration policies
■ Supports Traffic Class 0 and one virtual channel
■ Supports Message Signaled Interrupts (both MSI and MSI-X) as well as INTx
interrupt signaling for legacy PCI support
■ Supports end-to-end CRC (ECRC) and Advanced Error Reporting
