8 Sun StorageTek PCI Express SAS 8-Channel Internal HBA Installation Guide • January 2009
HBA Drivers
Your SG-XPCIE8SAS-I-Z adapter requires the correct drivers if it is to perform
properly. The drivers you need depend on your OS, and can be found on the Tools &
Drivers CD for your server.
There are various ways to make sure that you have the correct drivers:
■ If you use the Sun Installation Assistant (SIA) to install a Linux or Windows OS,
the correct drivers will automatically be installed for you.
■ If you install a Linux or Windows OS manually, you need to obtain the drivers
from the Tools & Drivers CD and install them yourself.
■ If you install a Solaris OS, the drivers are included in the OS for Solaris 10 8/07
and later versions.
The Tools & Drivers CD
A Tools & Drivers CD is delivered with your server.
You can also download an ISO image of the Tools & Drivers CD from the Sun web
site.
▼ To Download a Tools & Drivers CD Image
TABLE 2-2 shows an active URL for the Tools & Drivers download site for each host
platform.
TABLE 2-2 URLs for Tools & Drivers CD Images
Host Platform URL for Tools & Drivers CD
Sun Ultra 40
M2
workstation
http://www.sun.com/desktop/workstation/ultra40/downloads.jsp
Sun Fire X4140
server
http://www.sun.com/servers/x64/x4140/downloads.jsp
Sun Fire X4150
server
http://www.sun.com/servers/x64/x4150/downloads.jsp
Sun Fire X4240
server
http://www.sun.com/servers/x64/x4240/downloads.jsp
