8.1 INPUT COMMANDS FORMAT
The scale can be controlled with the following commands. The commands must be sent in
upper case letters, i.e. “T” not “t”. Press the Enter key of the PC after each command.
T<cr><lf>
Tares the scale to display the net weight. This is the same as pressing
[Tare]  key.
Z<cr><If>
Sets the zero point for all subsequent weighing. The display shows zero.
P<cr><lf>
Prints the results to a PC or printer using the RS-232 interface. It also
adds the value to the accumulation memory if the accumulation function
is not set to automatic. In CCT series, the [Print] key will either print the
current items being counted or the results of the accumulation memory
if [M+] is pressed first.
R<cr><lf>
Recall and Print- Same as if first the [MR] key and then the [Print] key
is pressed. Will display the current accumulated memory and print the
total results.
C<cr><lf>
Same as pressing [MR] first and then the [CE] key to erase the current
memory.
8.2 RS-232 SETUP
The RS-232 interface uses parameters set by the user for language, baud rate and date
format.
Press the [SETUP] key to access the parameters. Press [1] or [6] to scroll through the ‘RS-
232’ option and [Tare]  to confirm.
When a parameter is entered by pressing [Tare] , the displays will guide you through the
parameter selected and the options available.
The parameter and their functions are:
Print (to printer): Option for printing to a printer.
PC (continuous): For continuous printing.
Cmd (from device): For printing from a device.
Available options when selecting the ‘print’ option (use the [Tare] key to select). For each
setting it is possible to scroll through the options using [1] or [6] keys and pressing the tare
button to confirm.
