Suggested Calibration weights for CCT Series:
CCT 4 CCT 8 CCT 16 CCT 32 CCT 48
2 kg / 5
Ib
4 kg / 10
lb
10 kg / 30
lb
20 kg / 50
lb
30 kg / 100
lb
• After calibration, the scale should be checked whether the calibration and linearity is
correct. If necessary, repeat calibration.
NOTE: In certain regions, CCT scales will have the lb or kg indicator on, to show the unit of
the weight requested. If the scale was in pounds before starting the calibration, the weights
requested will be in pound values or if the scale was weighing in kilograms then metric
weights will be requested.
8.0 RS-232 INTERFACE
The CCT Series are supplied with a USB and RS-232 bi-directional interface. The scale
when connected to a printer or computer through the RS-232 interface, outputs the weight,
unit weight and count.
Specifications:
RS-232 output of weighing data
ASCII code
Adjustable Baud rate, 600, 1200, 2400, 4800, 9600 and 19200 baud
8 data bits
No Parity
Connector:
9 pin D-subminiature socket
Pin 3 Output
Pin 2 Input
Pin 5 Signal Ground
The scale can be set to print text in English, French, German or Spanish.
The data will normally output in a label format if parameter Label=On. This format is
described below.
