56 3 Manual Data Input
3.1 Manual Data Input (MDI)
When the current tool has no values entered into the Feed and Speed
table the Feed and Speed dialogue will be opened.
Touch the Feed and Speed Location zone.
The Feed and Speed dialogue opens.
To adjust the values directly, enter a new value in the Feed, and/or
Speed fields.
Touch Use to activate the changes, or press Cancel to exit without
making any changes.
When the Use button is touched, the operator will be prompted to
“Press Start to run operation or Manual to cancel”.
Press the Start button to execute the change, or:
Touch the Manual button to cancel all changes.
