Manual Information
Model, Software and Features
This manual describes functions and features provided by 3500i as of
the following NC software numbers.
The machine tool builder adapts the usable features of the CNC to his
machine by setting machine parameters. Some of the functions
described in this manual may therefore not be among the features
provided by the CNC on your machine tool.
CNC functions that may not be available on your machine include:
Tool measurement with touch probes
The machine tool builder representative can assist with becoming
familiar with the features of the machine.
Many machine manufacturers, as well as HEIDENHAIN Corp., offer
programming courses for the CNC. We recommend these courses as
an effective way of improving your programming skill and sharing
information and ideas with other CNC users.
Intended place of operation
The CNC is intended for use primarily in industrially-zoned areas. Refer
to the respective installation manual for additional information.
CNC model NC software number
ACU-RITE 3500i CNC Software 689 871-01
