416 11 G-Code Edit, Help, & Advanced Features
11.4 Advanced Programming
Block # Block
N1410 G90 G0 Z.1
N1420 G61 Z#26 F#1
N1430 G68 C#3
N1440 G91 G41 G64 X.1 Y(#25/2) F#2
N1450 X .1
N1460 G3 X0 Y( (#25)) I0 J( (#25/2))
N1470 G1 X(ABS((ABS(#24)) (ABS(#25))))
N1480 G3 X0 Y#25 I0 J(#25/2)
N1490 G1 X( (ABS((ABS(#24)) (ABS(#25)))))
N1500 G1 G40 Y( (#25/2))
N1510 G68
N1520 G90 G0 Z.1
N1530 M99
