414 11 G-Code Edit, Help, & Advanced Features
11.4 Advanced Programming
G66/G67 Macro Programming
This example is a modal macro program to mill slots in a plate at
various locations. In contrast to the G65 (single-call macro) in Example
1, G66 (modal macro call) applies the macro to all subsequent moves,
until canceled by G67. Program G67 after the last slot location.
Block # Block
N1 O101 * SLOTCALL.G
N2 G90 G70 G0 G17
N3 T0 Z0
N4 X0 Y0
N5 T1 D.25 L 1 F30
N6 G66 P1255 X5 Y1 Z .1 A5 B12 C5
N7 X1 Y2
N8 X2 Y4
N9 G67
N10 G90 G0 T0 Z0
N11 X0 Y0
N12 M2
N13
N14 ["SLOTMAC.G
